Items |
Model |
||
|
Maximum paper width |
800mm |
1000mm |
1200mm |
|
Maximum printing width |
780mm |
980mm |
1180mm |
|
Printing repeat |
500-1200mm |
||
|
Maximum unwinding/ rewinding dia |
1500mm |
||
|
Gear format |
5mm per tooth (size different depends on material) |
||
|
The speed |
150-200m/min |
150-200m/min |
150-200m/min |
|
The thickness of tape |
0.38mm |
0.38mm |
0.38mm |
|
Air comsuption |
6KG, 0.6L/Min clear, dry, no water/oil AIR |
||
|
Dry type |
Electric heating, natural gasheating, ect. |
||
|
Film |
Paper |
Non-woven fabric/woven bag |
Carton |
Aluminum foil |
Material |
|
0.012-0.3 mm |
20-100 gs.m, 80-250gs.m, 100-350 gs.m |
15un-400mm |
50-300 gs.m |
Aluminum foil: 10-50um, paper:＜80g |
Thickness off paper |
|
BOPP,PVC,PE,PE film, tissue paper and other roll - like materials |
White card paper, kraft paper, grey white board, coated paper and other roll - like materials |
Non - woven fabric, woven bag, valve pocket, paper, film and other roll - like materials |
Carton preprinted surface paper, backing paper, paper, film and other roll materials |
Aluminum foil, paper, etc |
Material |
|
1.7mm/2.28mm/2.84mm（ The thickness varies according to the material） |
The thickness of plate |
||||
|
Aluminum foil applicable ink: water - based ink, solvent ink and UV ink Printing color group: 1 color -10 color, can meet different customer needs. Minimum color unit： 4 colors |
|
||||
There are six types of flexo printing machines commonly used in the printing industry.
Flexo printing machines are commonly used for printing packaging materials such as cartons, paper bags, plastic bags, flexible packaging films, and labels.
The principle of flexographic printing involves the use of a flexible printing plate, usually made of rubber or photopolymer material.
Flexographic printing presses include holds the paper roll, printing unit, boot the system, drying system, cutting & trimming and Stacking Sections.
